Star Crane Service provides crane rental service, 24 hours a day, 365 days a year all over India.
Quality matters alot.We have a team of trained operators and staff specialized in wind mill sector.
We have gained a reputation for delivering high-quality services at economical rates.
We offer crane of 50 to capacity on rental which is a lifting machine, generally equipped with a winder (also called a wire rope drum), wire ropes or chains and sheaves, that can be used both to lift and lower materials and to move them horizontally. Some of its prominent features are:
1. Nissan engine and chassis.
2. Original computer control.
3. Excellent working condition.
4. 4 booms with fly jib.
Boom :33ft-105ft. (10.1m - 32m) four section, full-power synchronized boom. Maximum tip height: 112ft.(34.1m)
Swing :Planetary swing with foot-applied multi-disc brake.
Spring applied, hydraulically-released swing brake and plunger-type, one postion,
mechanical house lock opearted from cab.Optional 360 deg mechanical swing lock.Maximum speed:2.5 RPM
Hydraulic System :Three main gear pumps with combined capacity of 103 GPM(391 L/min), 135 GPM(511 L/min) with optional air conditioning.
Maximum operating pressure: 3500 psi(26.2 MPa)
Reture line type filter with full flow by-pass protection and service indicator.
Replaceable cartridge with micron filtration rating .System pressure test ports
Hoist Specification : Planetary reduction
with automatic spring applied multi-disc brake.Grooved drum.Electronic hoist drum
rotation indicator and hoist drum cable followers.
Maximum single line speed : 588 FPM
Electrical System : Two 12-volt maintenance free batteries, 12-volt starting and lighting, circuit breakers.Optional battery disconnect switch.
Engine : Cummins 6BT 5.9L diesel, six cylinders , turbocharged, 165 bhp (123 kw) @2500 rpm, Maximum torque:414 ft.lbs(561 Nm)@1,600 RPM
Steering : Fully independent power steering:
Front: fully Hydraulic, steering wheel controlled.
Rear: full hydraulic, switch controlled.
Provides infinite variations of 4 main steering Modes: front only, rear only, crab and coordinated
Star Crane and Hoist has been in business for 20 years, serving your overhead crane and hoist needs.
We are a family owned business with a rich history in delivering customer service. Our company specializes in helping commercial, residential and industrial clients with their crane rental needs. Our equipment and operators are all certified and insured. With a superior staff on hand, we will get you the proper equipment to best fit your application at the best price.
Star Crane Service provides crane rental service, 24 hours a day, 365 days a year all over India. Providing a range of 10-100 tonnes capacity cranes, ancillary equipment and personnel to ensure your crane requirements are met and run smoothly.
